Description
The Allen & Heath ZED-6FX 6-channel mixer offers great sound quality for small-format mixing applications. Two mono channels with acclaimed GSPre preamps are ready to accept mics (dynamic or condenser), instruments, or line-level sources. Two stereo channels are perfect for synths, drum machines, and other line-level sources. Add reverbs, delays, and combinations of the two with built-in effects processing. All this in a compact yet rugged design, with rotary controls secured to the front panel with a steel nut for maximum durability. For small PA and studio applications from schools and churches to corporate settings, the Allen & Heath ZED-6FX is a strong mixing solution.
Features
- Rugged compact mixer for small-format applications
- Multimodel effects include reverbs, delays, and combination effects
- 2 mono channels with GSPre mic preamps and instrument/line-level inputs
- Low-cut filters to reduce rumble and other unwanted low frequencies
- Effective sound shaping from HF and LF equalizer controls
- Channels can be individually assigned to the headphone mix
- XLR outputs for studio monitors or powered PA speakers
- Smooth 60mm fader for controlling your main mix
- Rotary controls are secured to the faceplate with steel nuts for maximum durability
| Tech Specs | |
| Type: | Analog mixer |
| Channels: | 6 |
| Faders: | 1 x 60mm Master Mix fader |
| Inputs - Mic Preamps: | 2 |
| Phantom Power: | 2 |
| Inputs - Line: | 2 x 1/4" (line/instrument) |
| Inputs - Other: | 4 x 1/4" TRS (stereo paired) |
| Outputs - Main: | 2 x XLR (left, right) |
| Outputs - Other: | 1 x 1/4" (FX out mix) |
| Headphones: | 1 x 1/4" |
| EQ Bands: | 2-band EQ |
| Effects: | 24-bit Mulit-effects, 99 presets |
| Height: | 3.5" |
| Width: | 9.8" |
| Depth: | 9.3" |
| Weight: | 3 lbs. |
